Are you looking to take advantage of remodeling your shop and get more opportunities to do a wide array of jobs?

Great output for compact size monoblock structure that will fit right where your old saw is sitting now !!!!

Denver has the solution for you!

SKEMA 180° -  4 axis bridge saw

Monoblock structure to maximize space saving and simplify installation

The SKEMA180 is a 4-axis machine with fixed tilt table and 180° motorized head rotation for square and variously oriented diagonal cuts, as well as 45° mitering.

The SKEMA 0-180 is the right fit for many shops doing primarily kitchen tops and vanities, and who also want the ability to do more complex tasks.

Types of work possible with SKEMA 0-180°

Machine foot print: 20’3”X 12’4” x 8’5”

- Axis Stroke: X axis 137” – Y axis 74” – Z axis 14”

- Motorized rotation of the head: 0° - 180° driven by inverter

- Manual inclination of the head: 0° -  90°

- Motor: 15 HP/ KW 11 (S6) with ability to adjust blade rpm from 800 to 3,000

- Blade size (min. - max.):  Ø 14” – 20”

- ELECTRICAL REQUIREMENTS : 208 V 60 HZ (54 Amp.), other voltages are also available

- WATER Requirement: 8 gal/min(Pressure 40 PSI )

>Structure of hot galvanized steel

>Safety barriers

>Pendant Remote Control and Touch screen controller for automatic cut programming

>Hydraulically Tilting Table with 3cm thick Okumé wood cover

>Laser for easier cutting.

>UL Certified Electrical cabinet

Transportation, Installation and Training + 1 blade

FINANCE OPTIONS AVAILABLE – NO DOWN PAYMENT !

FAST APROVAL TAKES ONLY 24 HOURS
